RAXIAL S8, Inline Booster Duct Fan 8" with Speed Controller

$49.99 $29.99
30-Tage-Bestpreis: 483.27 USD
Dies ist der niedrigste Preis des Produkts in den letzten 30 Tagen, bevor die Preissenkung angewendet wurde.
Energy Efficiency Class F
  • A duct fan designed to boost airflow in HVAC systems and ventilate home spaces like attics and workshops.
  • Features a variable fan speed controller, enabling you to optimize airflow and noise level for any application.
  • Unibody die-cast construction with no welded seams; reduces vibration while ensuring smoother airflow.
  • AC brushless motor with steel blades and lubricated bearings; not suitable in restricted airflow applications.
  • Duct size: 8" | Dimensions: 7.28 x 7.87 x 7.87 in. | Airflow: 428 CFM | Noise: 43 dBA | Bearings: Dual Ball
  • Die Kundenbetreuung
Produktbeschreibung
Technische Daten
   Product Identification
   Manufacturer    AC Infinity Inc.
   Product Name    RAXIAL S8
   Product Model    AC-RXS8
   UPC Code    819137021129
   Product and Mounting Dimensions - Fan Unit
   Duct Size    8"
   Total Dimensions    7.28 x 7.87 x 7.87 in. (18.5 x 20.0 x 20.0 cm)
   Cord Length to Controller    72 in. (6 feet)
   Cord Length to Plug    36 in. (3 feet)
   Product and Mounting Dimensions - Controller
   Total Dimensions    2.95 x 1.49 x 1.18 in. (7.5 x 3.8 x 3.0 cm)
   Required Mounting Area    1.49 x 1.18 in. (3.8 x 3.0 cm)
   Hole to Hole Distance    1.88 in. (4.8 cm)
   Screw Hole Diameter    0.197 in. (0.5 cm)
   Product Performance and Technical Specs
   Maximum Airflow    428 CFM
   Total Noise    43 dBA
   Static Pressure    2.45 mm-H20
   Operating Voltage    110V-120V AC
   Power    46 W
   Current    0.80 A
   Operating Humidity    35 to 85% RH
   Operating Temperature    40 to 140°F
   Fan Bearings    Dual Ball Bearing
   Mounting Positions    Horizontal or Vertical
   L10 Life Expectancy    67,000 Hours
   CE Cert. (Whole Product)    Product Manual PDF
   RoHS Cert. (Whole Product)    Product Manual PDF
   Product Manual
   Product Manual    Product Manual PDF
